The DC-ST100 is a high-capacity in-line stacker for the Duplo DC-648, DC-746 and DC-746 B2 slitter/cutter/creasers. It collects finished business cards, postcards and tickets in volume, and operators can pull completed stacks while the machine keeps running. That means fewer stops and up to six times the stacking capacity of the standard delivery.

Batch separation is fully programmable. Job changes can be triggered from the PC controller or by an optional 2D barcode scanner, so the stacker adjusts automatically to new layouts and piece sizes.

Specifications

• Works with: DC-648, DC-746, DC-746 B2
• Card sizes: from 1.88″ x 3.14″ up to 14.56″ x 8.5″
• Paper weight: 230–400 gsm
• Maximum stack height: 40 mm

Request a quote and ARI Graphics will confirm the right connecting kit for your machine.
